In this way, cabinet layouts can be finalised at the design stage rather than being left to guesswork or ordered at the last minute.ĭesignSpark Electrical will automatically compile a Bill of Materials for each project, comprising every part you have added to the design. Ancillary parts such as rails, ducting and even the cabinets themselves can also be added easily using the bespoke tools in the ribbon bar. In Version 1.1 of DesignSpark Electrical, price and availability data for RS parts can be accessed when selecting devices, ensuring that your design will not only be functional but will be within budget and to schedule.ĭesignSpark Electrical allows for the creation of accurate scaled 2D cabinet layouts by simply dragging and dropping 2D footprints of devices from the browser into the design.
The integral parts library holds more than 250,000 parts, with millions more available in the online portal, meaning you can quickly find and select the parts for your design. The built-in intelligence of the software will also ensure that designs are accurate and coherent.Ī comprehensive range of symbols are available within DesignSpark Electrical, complemented by a vast array of manufacturers parts for inclusion in designs. Tasks such as wire and device numbering are automated, as are reports, saving you huge amounts of time. These standard files are accepted by PCB fabrication companies and are used to build a printed circuit board.DesignSpark Electrical provides a powerful and comprehensive range of professional CAD capabilities, allowing you to complete designs in a fraction of the time and building accuracy and precision into your end-to-end design process.Ĭomprehensive range of specialist electrical design featuresĭesignSpark Electrical is genuine electrical CAD and offers a complete range of specialist features to optimise your design process. Components can also be auto-placed.ĭesignSpark PCB produces Gerber and Excellon drill files. A design may have several iterations before a finalised printed circuit board is passed for production.ĭesignSpark PCB includes an auto-router which automatically places tracks between components on a PCB layout. A PCB layout editor is then used to refine the physical layout of the printed circuit board. Schematics are translated to a PCB layout file with a PCB Wizard. There are some useful third party libraries that can be added. A given project can have multiple schematic sheets that together combine to form the complete design. Schematics are used to draw up circuit diagrams and connections. A project can have an unlimited number of schematic sheets and one PCB layout file.ĭesignSpark PCB has a Schematic editor. Projects are used in DesignSpark PCB to organise design files. DesignSpark resulted from a collaboration between electronics distributor RS Components and EDA software developer Number One Systems.
